  • What factors cause dimensional instability in NC machining? ​ ​
  • Editor of this station:Hangzhou Yitie Precision Machinery Co., LtdDate of issue:2018-05-30 16:49 Number of Views:


1, rolling bearing wear or improper adjustment, resulting in excessive movement resistance. This fault phenomenon is also usually shown in the size of a few wire within the range of irregular changes. The inspection can be carried out by the position deviation of DGN800-804, the same method as above. This kind of fault only needs to replace the worn bearing and adjust it carefully, and the fault can be eliminated

2. The connection between the servo motor shaft and the lead screw is loose, causing the lead screw and the motor to be out of sync, resulting in size error. When detecting, just make a mark on the coupling of the servo motor and the lead screw, and move the working table (or tool carrier) back and forth with a faster rate. Because of the inertia of the working table, the two ends of the coupling will appear obvious relative movement. This kind of fault usually shows that the machining size changes in one direction only and can be eliminated by fastening the coupling screw evenly.

3, CNC machine tool worktable (or tool rest) movement resistance is too large, generally for the insert adjustment is too tight, machine tool guide surface lubrication is poor. This fault phenomenon is generally shown as part size in a few wire range of irregular changes. The inspection can be carried out by observing the size and change of the position deviation of DGN800-804. Usually, there is a large difference when the positive and negative directions are stationary. Such faults only need to readjust the inserts and improve the lubrication of the guide rail.

4. Poor lubrication between ball screw and nut increases the movement resistance of the worktable (or tool rest), and it is unable to completely and accurately execute the movement instruction. This kind of fault is usually shown as part size in a few wire range of irregular changes, only need to improve the lubrication can eliminate the fault.
